PDC courses

PDC

Title

Instructor

1

Fan-Out, Chiplet, and Heterogeneous Integration Packaging

John H Lau  (Biography)

Unimicron Technology Corporation, Taiwan

2

Flip Chip Interconnects

Eric Perfecto (Biography)

IBM Research, USA

3

Co-Packaged Si Photonics: Opportunities and Challenges

Amr S Helmy (Biography)

University of Toronto, Canada

4

Design-on-Simulation Technology for Advanced Packaging Reliability Life Prediction

Kuo-Ning Chiang (Biography)

National Tsing Hua University, Taiwan

5

Automotive Electronics Reliability – Challenges and Opportunities

Pradeep Lall (Biography)

 Auburn University, USA



Fan-Out, Chiplet, and Heterogeneous Integration Packaging



Course Objective:

There are two parts of this lecture: First part of the course convers the Fan-out and chiplet design for 1 hour followed by second part of course covers the Heterogeneous integration packaging for 2 hours. For fan-out, the following topics will be presented and discussed: (1) Fan-out wafer/panel-level Packaging; (2) Formation of FOWLP, (a) Chip-First (Die Face-Down), (b) Chip-First (Die Face-Up), and (c) Chip-Last (or RDL-First); (3) Fabrication of Redistribution Layers (RDLs), (a) Polymer and ECD Cu + Etching, (b) PECVD and Cu Damascene + CMP, (c) Hybrid RDLs, and (d) Laser drill + LDI + PCB Cu-plating + Etching; (4) Formation of FOPLP, (a) Chip-First (Die Face-Down), (b) Chip-First (Die Face-Up), and (c) Chip-Last (or RDL-First); (5) TSMC InFO, (a) InFO-PoP, and (b) InFO_AiP Driven by 5G mmWave; (6) Samsung WLP/PLP, (a) PoP for Smart Watches and (b) SiP SbS for Smartphones; (7) Warpages, (a) Warpage Types and (b) Allowable of Warpages; (8) Reliability of FOWLP and FOPLP, (a) Thermal-Cycling Test, (b) Thermal-Cycling Simulations, (c) Drop Test, and (d) Drop Simulations; and (9) Examples, (a) Chip-First Panel-Level Fan-Out Packaging of Mini-LED for RGB-Display, (b) Chip-Last Panel-Level Fan-Out Packaging of Application Processor Chipset, (c) 2.3D IC Integration with Chip-First Fan-Out RDL-Interposers, and (d) 2.3D IC Integration with Chip-Last Fan-Out RDL-Interposers. Emphasis is placed on the fundamentals and latest developments of these areas in the past few years. For fan-in packaging, a six-side molded wafer level package and its reliability will be presented. The trends of fan-out and fan-in wafer-level packaging will be discussed. Chiplet is a chip design method and heterogeneous integration is a chip packaging method. Chiplet design and heterogeneous integration packaging have been generated lots of tractions lately. For the next few years, we will see more implementations of a higher level of chiplet designs and heterogeneous integration packaging, whether it is for cost, time-to-market, performance, form factor, or power consumption.



Course Outline:

(1)    System-on-Chip (SoC) and Why Chiplet Design?

(2)    Chiplet Design and Heterogeneous Integration Packaging:

a.        Chip partition and Heterogeneous Integration

b.       Chip split and Heterogeneous Integration

c.        Advantages and Disadvantages

(3)    Lateral Communication between Chiplets (e.g., Bridges):

a.         Bridge Embedded in Build-up Package Substrate

b.       Bridge Embedded in Fan-Out EMC with RDLs

c.        UCIe

d.       Hybrid Bonding Bridge

(4)    Chiplet Design and Heterogeneous Integration Packaging:

a.        Multiple System and Heterogeneous Integration with Package Substrate (2D IC Integration)

b.       (Multiple System and Heterogeneous Integration with Thin Film layer on the Package Substrate (2.1D IC Integration)

c.        Multiple System and Heterogeneous Integration with TSV-less (Organic) Interposer (2.3D IC Integration)

d.       Multiple System and Heterogeneous Integration with Passive TSV-Interposer (2.5D IC Integration)

e.        Multiple System and Heterogeneous Integration with Active TSV-Interposer (3D IC Integration)

(5)    Summary

(6)    Potential R&D Topics in Chiplet Design and Heterogeneous Integration Packaging.



Who Should Attend?

If you (students, engineers, and managers) are involved with any aspect of the electronics industry, you should attend this course. It is equally suited for R&D professionals and scientists. Each attendee will receive more than 300 pages of lecture notes.



Instructor’s Biography

John H Lau, with more than 40 years of R&D and manufacturing experience in semiconductor packaging has published more than 515 peer-reviewed papers (375 are the principal investigator), 40 issued and pending US patents (25 are the principal inventor), and 23 textbooks (all are the first author) such as Fan-Out Wafer-Level Packaging (Springer, 2018), Heterogeneous Integration (Springer, 2019), Semiconductor Advanced Packaging (Springer, 2021). and Chiplet Design and Heterogeneous Integration Packaging (Springer, 2023). John is an elected IEEE fellow, IMAPS Fellow, and ASME Fellow and has been actively participating in industry/academy/society meetings/conferences to contribute, learn, and share.

Flip Chip Interconnect by Eric Perfecto



Course Objective:

This course will cover the fundamentals of all aspects of flip chip assembly technologies, including various type of wafer bumping technologies, solder joint formation, non-solder joints and assembly considerations. The course is divided into two sections. The first section focuses on the key steps of flip chip assembly technologies and their associated equipment and materials. The second section dives into the depth of the fundamental aspect of flip chip technology. It will detail the various interconnect technologies used in today’s flip chip assembly. It will discuss the various under-bump metallurgy (UBM) fabrication methods (electroplating, electroless plating and sputtering) and solder depositions methods (electroplating, ball drop, IMS, and solder screening). The course will cover the various failure modes related to bumping, such as barrier consumption, Kirkendall void formation, non-wets, BEOL dielectric cracking, etc.  Special focus of the course will be on fine pitch technologies, mainly u-Pillar and Hybrid bonding.



Course Outline:

·         Introduction to Flip Chip Technologies

·         Flip Chip Technologies: Mass Reflow vs Thermal Compression Bonding

·         Packaging Technologies

·         Bumping Ground Rules

·         Flip Chip Under-Bump Metal and Intermetallic

·         Flip Chip Solder Deposition Processes

·         Cu Pillar Technology

·         Hybrid Bonding



Who Should Attend:

The goal of this course is to provide the students with a comprehensive understanding of flip chip fabrication and its use on the various advanced packages. Students are encouraged to bring topics and technical issues from their past, present, and future job function for group discussions.



Instructor’s Biography

Eric Perfecto has over 40 years of experience working in the development and implementation of C4 and advanced Si packages at IBM and GlobalFoundries. Eric’s responsibilities include UBM and Pb-free solder definition for C4 and u-Pillar interconnect, and yield improvements in C4 and 3D wafer finishing. He holds a M.S. in Chemical Engineering from the University of Illinois and a M.S. in Operations Research from Union College. Eric has published over 80 external papers, including two best Conference Paper Awards and the 1994 Prize Paper Award from CMPT Trans. on Adv. Packaging. He holds 60 US patents and has been honored with three IBM Outstanding Technical Awards. Eric was the 57th ECTC General Chair in Reno, NV, and the Program Chair at the 55th ECTC. Eric is an IEEE Fellow, an EPS Distinguish Lecturer and EPS VP of Education.



Co-Packaged Si Photonics: Opportunities and Challenges



Course Objective and Outline:

This course will overview the tools, technologies and approaches which enable Si photonics to empower the co-packaged optics initiatives pursued by the industry presently. The capabilities offered by existing Si photonics dictate, to a large extent, the advantages offered by co-packaged optics to the CMOS eco-system. Abilities for co-packaged topics to positively fuel scaling system in a package (SiP) by enhancing the interconnection density will be used as an example in this course.



This comprehensive course aims to provide a thorough exploration of the fundamental tools, cutting-edge technologies, and innovative approaches that underpin the remarkable potential of Silicon (Si) photonics in driving and supporting the ongoing co-packaged optics initiatives within the current industry landscape. As the industry places increasing emphasis on co-packaged optics as a strategic direction, understanding the intricacies of Si photonics becomes pivotal, as its capabilities and functionalities wield a significant influence over the advantages that co-packaged optics can bring to the broader CMOS ecosystem.



Who Should Attend:

The goal of this course is to provide the participants with a multifaceted analysis of Si photonics, examining its foundational principles, engineering intricacies, and diverse applications. By grasping the core attributes of Si photonics, course participants will gain a profound insight into the pivotal role it plays in shaping the co-packaged optics landscape. One noteworthy aspect that will be highlighted is how the inherent capabilities of Si photonics serve as a linchpin for the advantages conferred by co-packaged optics. This relationship will be elucidated through illustrative examples, such as the way co-packaged optics can significantly augment the scalability of Systems in Package (SiP) through heightened interconnection density. Through a systematic exploration of these interconnected concepts, participants will not only foster a comprehensive understanding of Si photonics and co-packaged optics but also develop a discerning perspective on how these elements synergistically contribute to the evolution of modern packaging technologies. By the course's conclusion, attendees will be equipped with not only theoretical knowledge but also practical insights that can be harnessed in real-world scenarios, enabling them to make informed decisions and innovations in the dynamic realm of co-packaged optics and Si photonics. As the industry landscape continues to be shaped by rapid advancements, this course stands as an invaluable resource for those seeking to navigate the intricate interplay between Si photonics and co-packaged optics, ultimately empowering them to drive forward advancements in system integration, interconnectivity, and performance optimization.



Instructor Biography:

Amr S. Helmy is a professor in the department of electrical and computer engineering at the University of Toronto. Prior to his academic career, Amr held a position at Agilent Technologies - UK, between 2000 and 2004. At Agilent his responsibilities included developing lasers and monolithically integrated optoelectronic circuits. He received his Ph.D. and M.Sc. from the University of Glasgow with a focus on photonic integration technologies, in 1999 and 1995 respectively.



His research interests include photonic device physics, with emphasis on plasmonic nanostructures, nonlinear and quantum photonics addressing applications in information processing / sensing, and data communications. Amr is an active volunteer and leader of the IEEE Photonics Society, currently serving as an Elected Member of the Society’s Board of Governors and as a Distinguished Lecturer. He was also the recipient of the Society’s 2019 Distinguished Service Award.



Design-on-Simulation Technology for Advanced Packaging Reliability Life Prediction



Course Objective and Outline:

The electronic packaging (EP) community has widely used Design-on-Simulation (DoS) technology for designing a new packaging structure. Still, it has encountered some challenges in ensuring a trustable simulation result. AI/machine learning approaches can be combined with DoS to solve this uncertainty. This course will use wafer-level packaging (WLP) to illustrate the solution methodology and procedure, including the FE model, mechanics theories, controlled mesh size validation, large database generation, and AI training performance of different machine learning algorithms. This talk will also describe how to combine AI and finite element simulation to estimate the reliability life of wafer-level packaging and obtain the best structure combination of each packaging component. This course will cover the following topics: (1) Finite element simulation, (2) 2D/3D model, (3) Material constitutive equations, (4) Mesh size control concept, (5) Simulation theory/materials/model validation procedure, (6) Solder joint reliability life cycle prediction empirical equations, (7) AI-Assisted DoS.



Who Should Attend:

This course aims to provide students and engineers with a comprehensive understanding of how to properly combine mechanics theories, constitution equations of material, finite-element modelling, and reliability life prediction empirical equations to estimate the reliability life cycle of area array type advanced packaging. Attendees are encouraged to bring topics and technical issues from their past, present, and future job functions for group discussions.



Instructor Biography:

Professor K. N. Chiang received his PhD from the Georgia Institute of Technology, USA. He is the Chair Professor at the National Tsing Hua University in Hsinchu, Taiwan. After graduating from Georgia Tech, he worked four years as a senior researcher at MSC/NASTRAN, a world-famous finite element system. From 2010 to 2013, he served as General Director of the National High-Performance Computing Center, which is the National Strategic Research Center of Taiwan. He has received outstanding research awards from the Ministry of Science and Technology of Taiwan three times and has published more than 450 technical papers in international journals and conference proceedings. He has been granted more than 50 invention patents. Among the major awards Professor Chiang received are the Excellence in Mechanics Award from ASME (2022) and the Outstanding Sustained Technical Contribution Award (2020) from IEEE-EPS. Currently, he is Editor-in-Chief of the Journal of Mechanics (SCI), Academic Editor of Materials (SCI), and Associate Editor of the Journal of Electronic Packaging (SCI). He is an IEEE, ASME, STAM, and IMAPS Fellow. And an academician of the International Academy of Engineering (IAE).



He has made significant achievements in simulation-based science and technology. He successfully combined simulation design with artificial intelligence technology and applied it effectively to semiconductor-related designs. His technology has greatly reduced product development time and development costs. He has worked with many major electronic packaging, semiconductor and LED companies such as ACET, TSMC, MediaTek, UMC, EPISTAR, VIA, Powertech Technology, etc.



Automotive Electronics Reliability – Challenges and Opportunities



Course Objective and Outline:

The modern car has increased semiconductor content and dollar value.  Semiconductors enable the majority of innovations in automotive.  The increased emphasis on autonomous driving and the electrification of vehicles has resulted in enormous changes for semiconductors and packaging.  The design, materials, and reliability strategies for automotive electronics will be presented.  Electronics are increasingly being used in automotive platforms for various mission-critical and safety-critical activities, such as guidance, navigation, control, charging, sensing, and operator interaction.  Over the last two decades, automotive platforms have expanded to incorporate hybrid and fully electric vehicles.  Much of the electronics is located under the car’s hood or in the trunk, where temperatures and vibration levels are far higher than in consumer office applications.  During the vehicle’s use-life, electronics in the automotive underhood may be exposed to sustained high temperatures of 125-150°C for extended periods.  The Automotive Electronics Council (AEC) has graded electronics for automotive purposes into four categories: grade 0, grade 1, grade 2, and grade 3.  Grade-0 components have the most demanding criteria of the four grade categories, with predicted power temperature cycling ranging from -40°C to +150°C for 1000 cycles and ambient temperature cycling ranging from -55°C to +150°C for 2000 cycles.  Furthermore, the grade-0 components are expected to be capable of sustaining high-temperature storage for 1000 hours at 175°C.  With the introduction of new packaging architectures, packaging applications have continued to evolve, allowing for powerful computing on mobile automobile platforms.  New materials and integration technologies have also emerged, allowing for tighter integration of electronics sensing and processing into the structural characteristics of the vehicle.  The automobile platform faces a series of constraints particular to the real-time context for enabling sophisticated functionality.



Specifically, the course will encompass the following topics:



1.       Role of electronics on the automotive platform

2.       Automotive environments

3.       Zero-Defects

4.       Second-Level Solder Interconnect Design Considerations

5.       Copper Wirebond Interconnects

6.       Advanced Packaging Interfaces

7.       Vibration Effects

8.       Sustained High Temperature and Wide Thermal Extremes

9.       Corrosion Propensity

10.    Accelerated Testing



Who Should Attend:

The goal of the course is to provide the students with a comprehensive understanding of the materials and reliability considerations in the design of electronics for operation in the automotive platform.  The course is intended to have an intermediate degree of difficulty to serve as an introduction for engineers and managers looking to design electronics for operation in the automotive underhood.



Instructor Biography:

Pradeep Lall is the MacFarlane Endowed Distinguished Professor and Alumni Professor with the Department of Mechanical Engineering.  He is the Director of the NSF-CAVE3 Electronics Research Center at Auburn University.  He holds Joint Courtesy Appointments in the Department of Electrical and Computer Engineering and the Department of Finance.  He is a member of the technical council and academic co-lead of automotive TWG and asset monitoring TWG of NextFlex Manufacturing Institute.  He is the author and co-author of 2-books, 15 book chapters, and over 900 journal and conference papers in the field of electronics reliability, manufacturing, safety, testing, energy efficiency, and survivability.  Dr. Lall is a fellow of the ASME, a fellow of the IEEE, a Fellow of NextFlex Manufacturing Institute, and a Fellow of the Alabama Academy of Science.  He is a recipient of the SEMI Flexi R&D Achievements Award for landmark contributions to Additive Printed Electronics, ASME Avram Bar-Cohen Memorial Medal, IEEE Biedenbach Outstanding Engineering Educator Award, Auburn University Research Advisory Board’s Advancement of Research and Scholarship Achievement Award, IEEE Sustained Outstanding Technical Contributions Award, NSF-IUCRC Association’s Alex Schwarzkopf Award, Alabama Academy of Science Wright A, Gardner Award, IEEE Exceptional Technical Achievement Award, ASME-EPPD Applied Mechanics Award, SMTA’s Member of Technical Distinction Award, Auburn University’s Creative Research and Scholarship Award, SEC Faculty Achievement Award, Samuel Ginn College of Engineering Senior Faculty Research Award, Three-Motorola Outstanding Innovation Awards, Five-Motorola Engineering Awards, and over Forty Best-Paper Awards at national and international conferences.  Dr. Lall is the founding faculty advisor for the SMTA student chapter at Auburn University and a member of the editorial advisory board for SMTA Journal.
